  1. Dave! Bloody hell she's all done. Congratulations mate. What a beauty. Absolute top job. I bet you are a proud owner. Still trucking over here in little ol NZ. Built another boat. ..... Have to do something in the evenings. Hope you enjoy your craft. She's looking great. Regards Lance boardman
  2. The ocracoke will handle 4-6 people no probs. They ride and beautifully and are powered by a relatively modest amount of hp considering the size of the boat. ( and they are a big 20 ft boat) The build us quite straight forward and very strong. One thing I really liked about the hull was the chine detail whereby the chine is part of the hull, not a strip of timber tacked on the outside , it just looks better even though the caroliner lines have still been kept. They are a great boat. Well designed, strong, functional and good looking. If you are up to the build.... Which isn't hard , but will require a big commitment , then go for it. You won't be disappointed.
  3. All modern engines these days are brilliant. Its pretty much a case of what manufactures sticker you want on the cowling. Reguarding fuel tanks etc, you can really notice the weight differance on my boat with only the rear tank full. Each tank is 25 gallons but I only use the forward tank for general tooling around. It keeps the weight more central in the hull as opposed to alot of weight in the stern. Things might be different on the 24.... more boyancy due to larger hull etc. If I were to do it all again I would probaly just put in one large tank forward. (If I was to get one custom made to fit tightly between the bearers it would of been around 150 ltrs.) And maybe use the rear compartment as a wet locker/ fish bin etc. This in itself opens up another can of worms reguarding water in the cockpit and so on. But all I can say is just be careful how much weight you shove at the back of the boat because you will notice it when you put the throttle down. The 20 likes the engine trimmed in to keep her bow down so it can do its job of slicing through the water. More weight in stern= alot more trim in.
  4. I had this trouble a while back. I had my picture quota increased and was away again. I had to check with this random pic to make sure pc was working ok. Sorry Dave couldnt help myself. Your making great progress. Shes looking like a boat.
  5. Hey sorry for slow response fisherman. Have not been infront of pc for a while. No downriggers for me mate, just good ol fasion rod and reels on my boat. I like to keep things simple. cheers. Lance.
  6. Hi Dave. Things looking good mate. Interesting to see the plank fixing debate still raging. You will find screws and washers or wooden blocks will be the only way to go especially once you start side planking towards the bow. The flare means alot of thin strips to avoid snapping but they still need a hell of pressure to hold them firmly down against the first layer. No doubt you have a good block plane, they are worth there weight in gold once you start the spiling process on your veneers. One thing I found interesting was Grahams idea to use the Ashcroft method for the planking- running both layers of side veneers in the same direction, as opposed to double diagonal planking. Just hoping someone would shed some light on what the advantage of the Ashcroft method is. Your doing a great job. Shes looking great.
  7. Very smart looking craft Hokey well done mate. love the clear finish on the deck. And only 44lbs? Thats bloody good going.
  8. Build is looking great Dave. I procrastinated over weather or not to do limber holes as per plan. If the holes were not put in the underfloor compartments would obviously act as seperate boyancy chambers basically meaning you would have to puncture the hull about 12 times in different areas before she filled up. (you probaly should not be in charge of a boat if you can manage that). But with a free draining underfloor are it is a real piece of mind to know any water getting in will get out, and the boyancey problem is solved simply by placing polystyrine under all the floor panels. I used plastic re-bar chairs to hold the poly up off the hull to allow free draining. They are cheap, strong and wont rot being plastic and they worked a treat. I put scupper drain holes in the foot well in the cabin, so after a days fishing....( Its utterly staggering how far fish blood will splatter) I can get the garden hose right up into the cabin, wash everything down, and all water is gone within seconds out the drain plug (bung) at the transom as long as the hull is tipped up above level. The floor on mine is drained into a bilge eventhough its high enough above waterline to allow transome scuppers, I beach launch...and an oncoming wave will push water into hull. Where I mainly use the boat there isnt alot of swell plus the cabin and combings deflect 99% of all water so the poor old bilge pump has quite a boring life. You are deffinatly doing the right thing Dave, and making great progress shes looking fantastic mate.
  9. Mine will be quite a bit different to what you are building because I went to a portifino stern. There was a template on the mylar so you can use to make your formers to curve the transom panel. I cut mine out of 2 inch thick timber the more surface area under the ply helps keep the surfaces from undulating. I also used 3 laminations and left the third off until the sides had been planked, then the last layer locks over the sides. There is alot more ply to be added to outboard well etc but is easier to once hull is flipped. When I laminated the curved panels together I pre-drilled strips of timber and spaced them quite close together , right angles to the formers to provide even clamping pressure on ply. scattering screws all over the place makes for 'lumpy' surface as the ply trys to pull up between fixings. The panel will sring open abit once glue drys, but will pull around again once you fix it to beams. Be very carful doing this bit, as you have to keep the bottom of the panel slightly above the line of other stations to allow for planing angle as transom is tilted outwards around 15 degrees. Hope this helps. Looks like you are doing a great job... and more imortantly, you are enjoying your build.
  10. Hi Dave do you mean potifino constrcuction or the curved transome panel itself?
  11. A couple of new bits suck the boat. The keel strip made from 1.2mm 316 stainless. Had the edges upturned 7mm the full length of the hull. Went on very well and forms up to the bow eye nicely. After pre-drilling it I filled the whole thing up with thickened epoxy then spent an entire friday evening grovelling around under the boat whiping up tonnes of glue that poured out the edges as I went along and screwed it into place. Real mission but the end result is pretty good. The entry on the boat is so fine that the keel rollers were wrecking the paint and glass on the forward section. This will sort out that issue. Installed a shiny new alloy baitboard that also has 3 rod holders and knife slots at the back. Its nyalic coated so wont turn into a dull grey manky looking piece of s--t ever. very popular coating for aluminium boats over here. Good enough for the space shuttle..... Also installed carpet in cockpit.....went off kiwi gripping it. Carpet is just so much nicer on wet feet, non-glare and reduces noise. Draw backs are it can be hard to clean but a couple of mins with pressure washer and nice smelling chemicals and shes as good as new every time. Headlinning stuck on too.... Have nearly run out of things to do.
  12. Geez you were not joking about deer antler ... (my 4 year old son calls them horn-tlers) for the tracing tool. love oringinal ideas.I used a nail punch sharpened to a point and punched a dot through the mylar every inch or so then conected dots with pencil. Crude but effective. We wish you could be workin on the thing full time too mate.Keep pics comming.
  13. I have used International Perfection on my boat and the one before it. The stuff aint cheap but put on properly you can hardly tell the difference from a spray job, and its tough. My last boat was built in 2007 and after 3 years of abuse... beach launching, dive tanks and fish blood it still scrubbed up as good as new every time. I was bloody impressed. Hence the reason for using it again on my Ocracoke. There is a few things I have leant about it the hard way though. Put on atleast 2 undercoats. The stuff sands back beautifully but in doing so you are also rubbing back your base coat so you end up exposing glass if you go to hard. External corners are the worst. As for the top coats, I use a foam roller...which puts the paint on thinner than a brush but alot less chance of drips and runs. The finish coats are super glossy....like you could shave in the reflection, the first coat is easy because the undercoat is a dull white so you can see where you are going. The second top coat is very hard to see the wet edge, even after you have rubbed it down with 320 grit. Also 2nd coat must be applied within a couple of days max of first coat as 1st coat hardens so much the 2nd wont stick properly. I found this out the hard way a few years ago.... It was like trying to put paint onto a greased piece of glass. All this info is on the back of the tin. Like I said if done right the results are impressive and very hard wearing. The stuff aint designed to be sprayed as thinning it will deminish the gloss levels but care taken with some rollers and a brush and you will have a top notch job. Its worth the money.
  14. If it were me I would put in a tank mate. I never really get a massive urge to go for a swim in a bay that is packed with yatchs.
  15. Masked up and rolled on kiwigrip.Goes on really easily. Removing the masking while its still wet was a bit tricky, but other than that all went well and looks good. Certainly looks grippy.Next will be going up around the bow with it.
×
×
